The DSC/DLC User Manual provides full guidance on the installation, wiring, configuration, and calibration of Mantracourt’s DSC (strain gauge digitiser card) and DLC (digitiser load cell) modules. It includes step-by-step instructions for mounting, wiring examples for RS232, RS485, and CAN interfaces, and details on using the free DSC Toolkit software for configuration, logging, and advanced calibration.
The appendices cover communication protocols (ASCII, Modbus RTU, Mantrabus II, MantraCAN, CANopen), command references, product codes, accessories, digital filtration, troubleshooting, and declarations of conformity.
This manual is the essential reference for system integrators and engineers looking to digitise strain gauge bridge inputs with high accuracy and flexible communication options.
