ICA H & S Product Sheet

The ICA series from Mantracourt offers high-performance analogue signal conditioners in a compact OEM format, specifically designed for embedding inside strain gauge-based sensors such as load cells, pressure transducers, and torque sensors. These miniature modules convert strain gauge signals into standard voltage or current outputs, delivering fast response and exceptional stability in a wide range of environments.

Available in six models, the ICA range includes high-performance variants (ICA1H to ICA6H) as well as the ICA5S for industrial-grade stability. The ICAH range is especially noted for its low drift over wide temperature ranges and excellent performance in harsh conditions.

Each amplifier is reverse polarity and short circuit protected, features a low-profile 7.6 mm height for compact integration, and uses a standardised 5 V excitation. The design includes multilayer PCB construction and advanced filtering to improve EMC performance. For applications requiring external packaging, the optional ILE (In-Line Enclosure) allows standard sensors to be converted to conditioned-output devices with ease.

Key Features:

Converts strain gauge signals to voltage or current outputs
Available in 6 variants including ±10 V and 4–20 mA options
Compact footprint with only 7.6 mm height
Excellent temperature stability and low drift (ICAH range)
Fast and simple calibration process
Short circuit and reverse polarity protection
Plated-through holes for secure wiring
Full CE approval and RoHS compliance
Optional ILE enclosure for external mounting
Ideal for embedded OEM applications

Typical Applications:

Load cells and force sensors
Pressure and torque transducers
Weighing systems and silos
Lifting and handling equipment
Automotive and motorsport (including embedded race-car telemetry)
Hazardous area installations (with ICA5ATEX variant)
