This user manual provides comprehensive setup, calibration, wiring, and troubleshooting guidance for the ICA Series of miniature strain gauge amplifiers from Mantracourt. Designed to support OEM integration into load cells and other strain-based sensors, the manual covers all six ICA variants (ICA1H–ICA6H and ICA5S), detailing their output configurations, power supply requirements, and filtering options.

The manual includes:

• Full electrical and mechanical specifications

• Step-by-step calibration instructions (including shunt calibration)

• Output configuration options (±10 V, 0–10 V, 4–20 mA, etc.)

• Wiring diagrams and recommended circuit layouts

• Notes on temperature stability and EMC performance

• Safety precautions including short-circuit and polarity protection

• Usage with the optional ILE (in-line enclosure)

• ATEX safety details for ICA5ATEX (where applicable)

This document is essential for design engineers, OEM integrators, and technicians working with embedded sensor solutions that require high-accuracy signal conditioning in compact formats.
