About
The LCD20 is a DIN rail–mounted intelligent load cell amplifier featuring isolated 4–20 mA and 0–10 V analogue outputs, two digital inputs, and two configurable relays. Designed for flexible integration with load cells, strain gauges, and pressure sensors, it offers easy setup via handheld programmer or PC Toolkit software. The document details key specifications, wiring, and configuration tools, including intuitive LC Toolkit functions for calibration, logging, and relay setup.
File type: PDF
Length: 4 pages
