The X24 Telemetry User Manual is a comprehensive technical guide covering the setup, configuration, and operation of Mantracourt’s X24 wireless ATEX/IECEx telemetry system. Designed for use in hazardous environments, the X24 range enables intrinsically safe wireless measurement of load, strain, and force using industry-standard strain gauge sensors.

This manual provides in-depth information on system components including transmitters, receivers, and integration options. Detailed wiring diagrams, calibration procedures, and radio configuration guidance are included to support both initial installation and long-term system performance.

Topics covered include:

• Intrinsic safety and certification details

• Hardware specifications and layout

• Radio settings and range optimisation

• Connection to strain gauge inputs

• Troubleshooting and diagnostics

• Maintenance and battery replacement

Ideal for technicians, engineers, and system integrators working in oil & gas, petrochemical, marine, and other ATEX-regulated industries, this manual is essential for achieving safe and accurate telemetry measurements in the field.

For use with the X24-ACMi-SA, X24-HD, and associated receivers.
