These drivers are for use in your own software and are supported by development platforms capable of using native Windows DLLs.

Contains example code for VB6, PureBasic, C#, C++ and Python.

Note that the installer installs to your Documents folder as programming environments cannot open and alter the source code if it was located in ProgramFiles folder.

T24AdvDrvxx.DLL

This Software title is licensed as FREEWARE. This means it is completely Free to use and can be copied and distributed freely as long as the following conditions are met:

• The source files on the original media cannot be changed in any way and must be distributed in full including any soft documentation.
• The software must not be packaged as an end user application. It must only be used as a configuration tool.
• There must be no charge for the software itself, although a charge may be made for duplication and/or media.
• Component software parts may not be used in third party applications without prior consent from the software author.

• The DLL drivers provide all the low level communications over USB or COM port to simplify communications with T24 modules. A T24 base station is required.Along with thread-safe callbacks for Data Provider messages, Wake Requests there is also support for accessing the built in spectrum analyser data and support for the T24-SAf fast acquisition modules.
  High level functions wrap up much of the complexity of T24 and allow:
  • Receipt of transmitted data
  • Pairing functions (including soft pairing)
  • Sleep and Wake control
  • Spectrum Analyser support
  • Reading and writing of device parameters
  • Control over base station channel changing
  • Supports system-wide RF channel changing
  • Handling Keep Awake and Stay Awake modes
  • Transmitting Data Provider messages

  Note: This replaces the previous set of DLL and COM drivers that were only available in 32bit. Contact Mantracourt if you would like these older drivers.



  This version fixes an issue when using serial port for both drivers.
